Connecting board assembly machine is a device used for automated assembly of electronic connecting boards and related components, widely used in the field of electronic manufacturing. The following is a detailed introduction to the body of the connecting plate assembly machine, including its working principle, functional characteristics, application areas, and advantages:

1. Working principle

The connecting plate assembly machine completes the assembly of connecting plates through an automated process, and its working principle mainly includes the following steps:

Raw material supply: The equipment receives various components of the connection board, such as shells, terminals, fixators, etc. These components are usually stored in silos or racks and are orderly separated and transported through vibrating discs or automatic feeding systems.

Automatic feeding: The feeding system takes individual components out of the silo and arranges them in the correct order to prepare for assembly.

Accurate positioning: Utilizing sensors and visual systems to identify and locate various components, ensuring they are accurately placed in predetermined positions.

Automatic assembly: A robotic arm or automated device performs assembly operations according to a preset program, including insertion, crimping, welding, and other steps.

Testing and Inspection: After assembly, the equipment will conduct electrical performance testing and visual inspection on the product to ensure quality.

2. Functional features

High degree of automation: It can achieve automation of terminal crimping, plugging, welding and other processes, significantly improving production efficiency.

High precision assembly: Ensure precise positioning and assembly quality of the connecting board components through visual systems and sensors.

Customized design: Equipment parameters can be quickly adjusted according to the specifications and design requirements of different connection boards.

Intelligent detection: equipped with multiple detection functions, real-time monitoring of product quality, ensuring product consistency and reliability.

3. Application Fields

The connecting plate assembly machine is widely used in the following fields:

Electronic manufacturing: used for the assembly of PCB connection boards, electronic connectors, etc.

Automotive electronics: used for assembling connection boards in automotive electronic devices.

Home appliance manufacturing: used for assembling connection plates for various types of home appliances.
